1,5-30 kW
8-10 bar
0,16-3,40 m³/min
Oil Free, Belt Driven
Scroll
Air Compressors
Your solution partner specially designed to meet 100% of the air needs in the food and beverage, chemical, pharma, and healthcare industries where oil-free air quality is essential.
Advantages
- Low noise level thanks to low-vibration operation.
- User-friendly, robust and long-lasting microprocessor control device with communication features based on the product smooth operation and interruption-free production.
- Component placement specifically designed to reduce downtimes during maintenance process.
General Features
- Compact design
- • Soundproofed canopy
- • Internal air cooler(s), water separator, and stainless pipes
- • Robust and durable single unit or stacked design
Main Motor and Drive System
- IE3 efficiency-class electric motors
- Belt-pulley drive system
- Easy belt tensioning system
Compressor Block
- Effective and oil-free scroll design
- Integrated cooling fan on the scroll unit for effective cooling
- Star/delta connection (3,7 kW and above)
Scroll Type Compression Principle
Orbital and fixed spiral elements align to create compression chambers.
The continuous movement of the orbital spiral compresses air from the atmosphere producing oil-free and pollutant-free air.
100% Oil-Free Compressed Air
- It is designed in accordance with sensitive and accurate production conditions.
- It protects the environment and saves energy.
- It is produced in accordance with all global standards and regulations.
- It prevents damage to your products and the contamination of your production lines.
- Therefore, it eliminates unnecessary machine downtime.
- It guarantees the high quality compressed air you need.
Controller
- Without the need for an external main controller, ability to co-aged work synchronized with Master/Slave for up to two compressors
- Internal ModBus communication
- User-friendly on-screen interface
- Alarm log records last 20 alarms
For double stage and above
- Weekly scheduler for starting/stopping the machine at 3 different time intervals can be individually set for each day of the week
- Maintenance warnings and log records
- Equal ageing through scroll units
- Automatic start/stop of units according to air demand
1,5-30 kW
8-10 bar
0,16-3,40 m³/min
TECHNICAL
SPECIFICATIONS
